Analog pH Meter with HI1230B Electrode
The HI83141 is a portable pH/mV meter designed to be accurate, reliable and easy to use. The HI83141 uses the HI1230B pH electrode and HI7669AW temperature probe using separate connections.
- Automatic Temperature Compensation (ATC)
- Two-point Calibration
- Compact, heavy-duty, and waterproof protected casing
Details
Specifications
|
sku |
HI83141 |
|
pH Range |
0.00 to 14.00 pH |
|
pH Resolution |
0.01 pH |
|
pH Accuracy (@25°C/77°F) |
±0.01 pH |
|
ORP Range |
±1999 mV |
|
ORP Resolution |
1 mV |
|
ORP Accuracy (@25°C/77°F) |
±1 mV |
|
Temperature Range |
0.0 to 100.0°C; 32.0 to 212.0°F |
|
Temperature Resolution |
0.1 °C (0.1 °F) |
|
Temperature Accuracy (@25°C/77°F) |
±0.4 °C; ±0.8 °F (excluding probe error) |
|
Temperature Compensation |
automatic, 0 to 70°C (32 to 158 °F) |
|
Calibration |
manual, two-point, via trimmers |
|
Power Supply |
9V batteries |
|
Power Consumption |
approximately 100 hours of continuous use |
|
Environment |
0 to 50°C (32 to 122°F); RH max 100% |
|
Dimensions |
145 x 80 x 36 mm (5.7 x 3.1 x 1.4’’) |
|
Weight |
230 g (8.1 oz.) |
|
Ordering Information |
HI83141 is supplied with HI1230B pH electrode and HI7669AW temperature probe, HI70004 pH 4.01 buffer solution sachet, HI70007 pH 7.01 buffer solution sachet, HI700601 electrode cleaning solution sachets (2), calibration screwdriver, battery, protective case and instructions. |
|
Warranty |
2 years |
|
Recommended Probe |
HI1230B PEI body pH electrode with BNC connector and 1 m (3.3’) cable (included); HI7669AW stainless steel temperature probe, BNC connector (included) |
